DOBC AC Module SMT Rectangular Type 18W

DOBC AC Module SMT Rectangular Type 18W
DOBC AC Module SMT Rectangular Type 18W

DOBC AC Module SMT Rectangular Type 18W

DOBB-18FxA-0xN
The Sheng Yeong DOB-COB LED light-engine delivers safe, reliable, compact size and energy-saving alternatives to traditional Fluorescent Lamp. The innovation design in LED space allocation provides uniform light distribution with high efficiency. The novel AC-LED driver which use no electrolyte capacitors further ensures lifetime of the lamp.


Inquiry
  • Feature
  • Specification
  • Directly AC line input, need no AC-DC power supply
  • Easy decorative lighting
  • RoHS compliant
  • Long lifetime designed to 50,000 hours L70B50
  • No UV
  • Mininaturized
Connect Type Hanging-mounted or Wall-mounted
Driver AC100~240V, 50/60Hz
Power 40W±10%
Luminous Efficiency 100 lm/w±5%
Lighting Effect 4000 lm±5%
Dimension (mm) (Hanging-mounted) Ø304 x 167(H)
(Wall-mounted) Ø304 x 252(H)
Color Temperature 3000K±400K / 5500K±500K
Beam Angle 60°/ 90°/ 120° Asymmetric Lens
Power Factor >0.95
CRI >70Ra
Ambient –20°C~50°C
Ingress Protection IP30 and IP65
Material Anodized Aluminum
Weight (Hanging-mounted) 1.5Kg
(Wall-mounted) 1.8Kg
